Overview:

Features: 10 / 8F - G type gravel pump is a introduced technology product. The pump adopts a single pump shell structure connected by a cassette. It is a single-stage single-suction cantilever centrifugal pump with light weight, good cavitation performance and abrasion resistance. Strong, wide flow passage, easy to install and use, etc., can continuously transport large particles of strong abrasive mud, suitable for dredger dredging, sand mining and sand dredging.
Structure: This series of gravel pumps consists of pump head, sealing assembly, bearing assembly, bracket, etc. The bearing lubrication method is grease lubrication. The over-flow component impeller, pump body, front guard plate and rear guard plate are all made of strong anti-wear high-chromium alloy or wear-resistant alloy steel with a hardness of not less than 58HRC.
Sealing form: packing seal, auxiliary impeller seal, packing plus auxiliary impeller seal, mechanical seal and other types.
Transmission mode: V-type V-belt drive, flexible coupling drive, gear reducer drive, hydraulic coupling drive, variable frequency drive, thyristor speed control, etc. A variety of speeds and a variety of variants allow the pump to operate under optimal conditions. Long service life and high operating efficiency can meet a variety of harsh conveying conditions.

Type meaning for dredge pump

10 / 8F - G

10----------------pump inlet size (inch )

8----------------pump outlet size (inch)

G----------------G gravel pump

G(H) gravel pump material list for parts:

Performance table:

Construction Drawing

Selection ＆ Performance Chart

Shijiazhuang ShizaPump Industry Co.,Ltd. founded in 2008, is a professional industrial pump manufacturer engaged in researching slurry pump, wear and corrosion resistant materials and OEM processing.

Shizapump group covers more than 40000 square meters, the registered capital is 18 million yuan. Over the years with strong strength and people-oriented concept, we absorb a large number of high-quality management and technical talents. Existing staff is more than 220 people, of whom 30% are technicians.

Our production area covers an area of 24000 square meters, the total production capacity of an annual output is 10000 units (sets), and the annual output of all kinds of high chromium alloy castings is 2000 tons.The production area is divided into five districts one area and two centers, namely mould casting, heat treatment, fine machining, forge welding and assembly coating of five production areas; finished spare parts; quality analysis and water experiment. The main material of products: A05, A49, A33, A51 and other high chromium white cast iron.

Shijiazhuang ShizaPump Industry Co.,Ltd. fully implements the ISO9001 management system and observes the process of inspection. Quality inspection records are available in all production processes. Professional instruments include spectrometer, metallographic analyzer, flaw detector, mechanical test machine (strain, impact, hardness), magnetic flowmeter, pressure gauge, ammeter, vibration meter, noise meter, hydraulic experimental curve of professional software. Perfect detection guarantees the quality of equipment to ensure that each pumps and parts are fully in line with the requirements.

Shijiazhuang ShizaPump Industry Co.,Ltd. has spread all domestic market in China over 30 provinces and municipality. Also has been successfully used in 20 countries in global .First line staff have professional experience to provide service for customers.
